Item | Parameter | |
Overall dimensions | Length | 10080mm |
Overall width | 2490 mm | |
Overall height | 2460mm | |
Work platform dimensions | Length | 2400mm |
Width | 900mm | |
Wheelbase | 2500mm | |
Maximum working height | 22m | |
Maximum platform height | 20m | |
Maximum working range | 16.6m | |
Maximum carrying capacity | 300 kg (Without limit)/ 460 kg (With limit) | |
Luffing range of boom | -3°~ +73° | |
Slewing angle of turntable | 360° | |
Tail swing of turntable | 1310 mm | |
Slewing angle of platform | 160° | |
Overall weight | 12460kg | |
Traveling speed | 6.3 km/h | |
Minimum turn radius | 6m | |
Minimum ground clearance | 230mm | |
Maximum gradeability | 45% | |
Tire specification | 36×14-20;355/55D625 | |
Engine model | Kubota V2403-CR-EW02 | |
Engine rated power | 36.8kw/(2700r/min) |
